On Short Rows – a guest post from Kate Atherley

Short rows are an incredibly useful technique in knitting. They’re used to create curves, change stripes, turn corners and add bust shaping.

Although simple in principle, they add a fair degree of complication to pattern instructions, and can be a particular challenge when building them into charted patterns.

Stichmastery makes the key element of dealing with short rows in charts entirely straightforward: there are tidy symbols available!

There’s a left-turn and a right-turn symbol.

Screengrab of two short row symbols

Their standard definitions are deliberately generic – short row right and short row left – because there are several different techniques for the turn and what happens around it.

There’s the classic “wrap and turn”, where a collar of yarn is placed around a stitch. The yarnover and shadow methods have you work an increase at the turn point; the German method has you create a doubled stitch. The Japanese method (and the associated variations), have you use a safety pin or removable stitch marker to mark the yarn at the turn point.

Classic wrap and turn

If you’re using the classic wrap and turn method, then the short-row symbol represents the wrap very nicely.

Knitting chart with a wrap and turn symbol

In this chart, the last stitch worked is number 5, and stitch number 6 is wrapped. The stitches after the turn symbol are marked as ‘no stitch’ to indicate that they aren’t worked; and in the row after the turn, there is an additional ‘no stitch’ symbol above the turn symbol since that stitch wasn’t worked, only wrapped and slipped.

The position of the turn symbol, working the wraps

It’s important to note the position of the short row turn symbol. It should be positioned AFTER the last stitch worked – put another way, the turn symbol is always placed where the gap is. The reason for this is simple: if you’re working in a pattern stitch, you need to show what do with the last stitch worked.

Knitting chart showing wrap and turn stitches appearing in line with purl and knit stitches

If you had placed the turn symbol on the last stitch worked, you’d lose the information that the final worked stitch of row 3 needs to be purled.

In this chart, I’ve also introduced another character. In the version 3 of Stitchmastery, there’s a new symbol in the Miscellaneous category, Pick Up Strands. I’ve used that, and would rename it in the key to “Work wrapped stitches together with wrap”.

The German and shadow method

For both of these methods, you’re acting on stitch 6. In the German version, you’re first slipping it then lifting it up and over to create a doubled stitch. In the Shadow method, you work a lifted increase to double up the stitch.

For either, the first time you work over the doubled stitch, you work both legs/strands together.

For the German version, I’ve created a custom symbol here in version 3, but the choice of the symbol is up to you. For the work both legs, I’ve just turned the symbol upside down.

In this case, the turn symbol is moved one stitch to the left, since you do actually work stitch 6 in row 3, before turning and creating the doubled stitch.

Knitting chart with customised stitch symbols

There’s actually an argument that you don’t need to include the short turn symbol at all. Without it, it looks like this:

Knitting chart showing customised stitch symbols

The decision is driven by whether you think the knitter would be helped by having a reminder about the significance of the ‘no stitch’ symbols here.

For the shadow method, I’ve used a double-loop sort of symbol, the ‘create the doubled stitch’ one way up; the ‘work the two strands of the doubled stitch’ symbol is the same thing, just upside down.

Knitting chart showing customised stitch symobls

The Yarnover method

To represent the Yarnover method in a chart, I’ve placed the yarnover symbol over the turn symbol. In this case, the yarnover is a new stitch, worked in the gap created by the turn. Although, technically speaking, this actually adds a new proto-stitch after existing stitch 5, we don’t need to adjust the width/stitch count of the chart, since that extra stitch-like-thing is immediately decreased away the moment you work over it. In this way, it’s like bobbles and nupps and Estonian gathered stitches. They’re increased on one row, and immediately decreased on the next, so there’s no real need to modify the chart size.

Knitting chart showing different symbols

In row 7, the k2tog is placed in column 6, as it is worked over stitch 6 and the yarnover that sits to its right. There’s no ‘no stitch’ symbol, since the stitch count stays constant at 10.

And again, the turn symbol could be considered optional. If you didn’t include it, stitch 6 in row 3 should be marked as a ‘no stitch’.

The Japanese & pinning methods

In the Japanese/pinning methods, nothing happens to the stitch on the first side, just a simple turn. A safety pin or removable stitch marker is clipped onto the loop yarn that runs between the last stitch worked on the one row, and the start of the next row. Often the first stitch worked on the returning row is slipped, as follows:

Knitting chart showing different symbols

And again, it’s your choice whether to include the turn symbol, although in this case I’d probably leave it in and adjust the description in the key with instructions for the pinning required.

For all the methods

The key, of course, is to clearly document the short row method you’re using in the pattern instructions – or of course, simply note that the method is the knitter’s choice. (In that case, it’s helpful to add a note to the pattern that the knitter must have short-row skills.)

And definitely make sure that the names of the symbols are helpful and correct. If you’re using it, change the name of the short row symbol, so it aligns with whatever method you’re using: “wrap and turn”, “turn”, “turn and pin”, etc. And if you create a special symbol for the other piece – create a double stitch, make sure that’s labelled properly, too.

The validation issue

No matter what method used, and whatever you’re doing with the symbols, there is one thing to be aware of.

In the current version of Stitchmastery, there’s a hiccup if you’re using the Outline feature to validate the stitch counts. Because of the different methods of working short rows, the system isn’t currently able to count the stitches accurately. Specifically, if you use the ‘no stitch’ symbol in a chart with short rows, the validation will fail.

Screenshot of Stitchmastery in action with failure in the validation area

The solution is simple, however: instead of the actual grey ‘no stitch’ symbol, just use the grey from the Colours menu.

Problem solved! Validation goes ahead! Just make sure you do a visual check of the rows that do have short rows, to make sure that your ‘no stitch’ symbols (and any other supporting symbols) are placed appropriately.

Screenshot of Stitchmastery with successful row validation

And know that Cathy and the team are definitely looking at ways of dealing with the validation for future versions – stay tuned.

Helping with translations

When we launched Stitchmastery Version 3, one of the key additions to the programme were German and Danish translations of both the system Stitch Libraries and the Text Templates stylesheets. We were able to add these thanks to designers who helped us with the translations. This addition to the software means that anyone who wouldContinue Reading

Stitchmastery Version 3.0.2

We’re pleased to let you know we have released an updated version of Stitchmastery – Version 3.0.2. This version has the following changes: – fix for bug that affected users with a machine set to a language other than English which prevented them editing stitch symbols – fix for bug that meant that stitches didContinue Reading

Stitchmastery Mac OSX Users – please read!

The latest version of Mac OSX, High Sierra, has been made public and there is a bug in it that affects Java applications including Stitchmastery. The bug disables the menus of Java applications rendering them unusable. It seems to affect only those users who have their operating system language set to something other than English.Continue Reading

How to add a Repeat or Border to a Stitchmastery chart

A little while ago I wrote gave some examples of how ‘Borders’ and ‘Repeats’ could be added to a Stitchmastery chart (Repeats and Borders on a Stitchmastery chart) and the differences that these made to both the visual appearance of the chart and to the written instructions that Stitchmastery automatically generates. The bottom line: ifContinue Reading

Publications using Stitchmastery – Knit Now

Last week I blogged about Knitty who have been using Stitchmastery to create all of their knitting charts for nearly 5 years. There is another magazine, though, that has been using Stitchmastery for just over 5 years and has a record number of editions (67!) published with charts created with the use of Stitchmastery. KnitContinue Reading

Publications using Stitchmastery – Knitty

One of the first publications to begin using Stitchmastery to create all of their knitting charts was Knitty. That was nearly 5 years ago in the Winter bis 2011 edition;- Save Save In that edition Knitty also published a review of Stitchmastery and explained the reasons why Knitty adopted Stitchmastery as their official charting software.Continue Reading

Get creative with lace knitting stitches.

How you ever thumbed through a stitch dictionary looking for exactly the right stitch pattern for a knitting project that you had in mind? Perhaps you have found a stitch patterns that’s almost right but not quite there? Or perhaps you want to find a stitch pattern that’s different from any that you’ve seen? InContinue Reading
